Unitec SKY2000-M4 Gas Detector with pump suction

UNITEC SKY2000-M4 Gas Detector CO/H2S/O2/EX

UNITEC SKY2000-M4 Pump-suction four-in-one Gas Detector can simultaneously detect carbon monoxide, hydrogen sulfide, oxygen, combustible gas four, SKY2000-M4 Gas Detector using electrochemistry and catalytic combustion principle.

Brand

SKU: NB009139

Unitec

Model

SKY2000-M4

Get Quote

Unitec

Information

Datasheet Catalog Manual

What else did others buy

Empaer AATL-H2 Pathfinder Series Stationary Hydrogen Detectors

$ 305.00
HUIRUIPU HRP-T1000-NH3 Ammonia Gas Detector (no display with light)

$ 215.00
BOSEAN BH-60-HCN Fixed Hydrogen Cyanide Gas Detector 0~10ppm

$ 241.00
HONEYEAGLE HNAG1000-NO2 Fixed Nitrogen Dioxide Detector 0-100PPM

$ 582.00
BH-60-Cl2 Fixed Gas Detector 0~50ppm

$ 241.00

Genuinegoods

Unitec SKY2000-M4 Gas Detector with pump suctionOverview
Specifications
Comments
FAQs

SKY2000-M4

Gas Detector with pump suction

Features

◆ SKY2000-M4 adopts original imported high precisionSensors for up to four gases to be detected at the same time

◆ USB interface for high-speed data transfer, downloadable and printable data (optional)

◆ Liquid crystal dot matrix display technology, which can display gas types, gas units,Gas concentration values, measured maximums, local time, ambient temperature, etc

◆ Support Chinese and English operation interface, simple and convenient switching

◆ The gas concentration unit PPM, mg/m3 can be quickly switched to display

◆ Built-in miniature sampling pump

◆ Explosion-proof qualification certification, explosion-proof grade: ExiaII.CT4

Product features

1. Monitor the gas concentration in the environment or confined space and give an alarm

2. With self-calibration function and zero point calibration function, the gas monitoring is more accurate and reliable

3. One-key factory reset function, which can avoid the trouble of misoperation

4. With temperature and pressure compensation, it can well realize the compensation of gas concentration in different temperature and pressure environments

5. Two-level sound and light alarm, and the alarm point can be set by itself

6. Large-capacity lithium polymer rechargeable battery

7. Pump suction sampling mode, the suction power of the pump is adjustable

8. The shell is made of high-strength special engineering plastics, which is anti-slip, waterproof, dustproof and explosion-proof

9. Exquisite and high-end aluminum alloy suitcase

Product Applications

● Furniture, flooring, wallpaper, paints, gardening, interior decoration and renovation, dyes, papermaking, food, corrosion

● Disinfection, fertilizers, resins, adhesives and pesticides, raw materials, samples, processes and breeding plants, garbage treatment plants, perm places

● Biology, home environmental protection, animal husbandry, greenhouse cultivation, warehousing and logistics, brewing and fermentation, and agricultural production in the production workshop

Display diagram

Yuante SKY2000-M4 pump-suction four-in-one Gas Detector display diagram

Yuante SKY2000-M4 pump-suction four-in-one Gas Detector structure diagram

Yuante SKY2000-M4 pump-suction four-in-one Gas Detector packaging drawing

Unitec SKY2000-M4 Gas Detector with pump suctionSpecifications

LIST	VALUE
Detect gas	CO、H2S、O2、EX
Sensors principle	Electrochemistry \| catalytic combustion
Sampling method	Pump suction
Range	0~1000ppm(CO)、0~100ppm(H2S)、0~30%vol(O2)、0~100%LEL（EX）
CO- resolution	1ppm
detection Accuracy	2%~3% F.S.
Interface	USB
Response time	≤10s
Repeatability	≤±1%
Linearity	≤±1%
Zero drift	≤ +/- 1% (F. S/year)
Display	LCD dot matrix display technology
Operating language	Support Chinese and English
Display unit	Multiple Gas Unit switch display
Operating temperature	-20~50℃
Environmental humidity	0~95%RH
Explosion-proof sign	Exia ⅡCT4
Protection level	IP66
Alarm mode	Sound, light, vibration
Operating Time	100H (turn off the pump)
Dimension	2057532mm
Weight	300g
EX- resolution	1%LEL
O2- resolution	0.1%VOL
H2S- resolution	0.1ppm

Unitec SKY2000-M4 Gas Detector with pump suction Packing list

machine X1, manual X1, certificate X1, warranty card X1

[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.

FAQ

[Q]

How many gases can the SKY2000-M4 Gas detector test simultaneously?

[A]

Hello, SKY2000-M4 Gas detector adopts imported high accuracy Sensors, which can detect up to four gases simultaneously.

[Q]

How to set the alarm function of KY2000-M4 pump suction four-in-one Gas detector?

[A]

Hello! The function settings of the instrument can be downloaded to the specific operation instructions at the bottom of the product page, and there are also specific picture instructions!
