YIHENG DHG-9245A Desktop Forced Air Drying Oven Input Power 2450W

Introduction

Yiheng DHG-9245A Forced Air Drying Oven adopts a stainless steel liner with a volume of 220L and a temperature control range of 10~300°C. DHG-9245A Forced Air Drying Oven is a product produced by professional laser and numerical control processing equipment, and has a microcomputer PID controller. Used for drying, baking, melting wax, and sterilization in industrial and mining enterprises, laboratories, and scientific research units.

Features

1. The DHG-9245A Forced Air Drying Oven adopts a microcomputer PID temperature controller with over-temperature deviation protection and digital display, with a timing function, and the temperature control is accurate and reliable. ,

2. The inside of the box is made of mirror stainless steel argon arc welding, and the outside of the box is made of high-quality steel plate, which is beautiful and novel in shape.

3. The air intake and exhaust volume in the box can be adjusted from the temperature control panel.

4. The hot air circulation system is composed of a fan that can operate continuously at high temperature and a suitable air duct to improve the temperature uniformity in the working room.

5. Using a new type of synthetic silicon sealing strip, it can run at high temperature for a long time, has a long service life and is easy to replace.

6. Independent temperature limit alarm system, which will be automatically interrupted when the temperature exceeds the limit, so as to ensure the safe operation of the experiment without accidents. (optional)

7. It can be equipped with a printer or RS485 interface, used to connect a printer or computer, and can record the change of temperature parameters. (optional)

Optional

1. Multi-segment programmable temperature controller

2. Independent temperature limit controller

3. RS485 interface and communication software

4. Embedded printer

5. Diameter Ф25mm test hole

6. U disk data storage

7. Wireless alarm system (SMS alarm system)

Pictures

host x1, instruction manual x1, packing list x1, warranty x1, warranty card x1, fuse x2, shelf x2, communication data cable x1, software CD x1, printing paper x1, U disk x1, UV lamp x1

[Note] Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
