JingKeLian TCJ Resilience Impact Device
The JINGKELIAN TCJ Impact Resistance Tester is a film resilience impact test that measures the performance of a film against cracking or substrate disbonding after impact.
JingKeLian TCJ Resilience Impact DeviceKey Spec.
Punch diameter
Φ15.9mm、Φ20mm
Impact height
1265mm
Drop weight mass
1000G, 2 pounds
TCJ Resilience Impact Device
Details
2 page unread, continue reading?
This manual is collected and sorted by the NBCLab, and does not guarantee the timeliness and accuracy. It is only for reference.
Continue to read
