Factory NBC-8516 Single Dropping Tester
The drop height of the CHINA NBC-8516 single-wing Dropping Tester is 300-1500mm, the maximum size of the specimen is 1000x800x1000, and the impact panel size is 1700x1200x10mm. The NBC-8516 adopts double-column guidance, and the height drop number can be set.
Factory NBC-8516 Single Dropping TesterKey Spec.
Test method
Face, corner, edge
drop height
300~1500mm
NBC-8516 Single Dropping Tester
Details
7 page unread, continue reading?
This manual is collected and sorted by the NBCLab, and does not guarantee the timeliness and accuracy. It is only for reference.
Continue to read
